RC Electronic Switch, Remote Control RC Relay Switch Max Current 1A Power On-Off LED Light Controller for 5~12V Receiver DIY Airplane Model Modify for RC Model Airplane Plane Accessories (Co

Specification:- Item name: CH2-L RC electronic switch / RC switch on off / RC switch modules / led light control board- Max current: 1A/channel- BEC output: no- 5-12V receiver power supply- With power-on protection, only at the middle position can enter the system- Without signal protectionControl mode: - Three-stage fluctuation switch channel:- The other channel work: low position 1000US- Two channels close: medium position 1500US- One channel work: high position 2000USApplication:- LED light remote control switch- Occasions requiring switch control- Power supply connection and disconnectionNote:- The load current can not be higher than receiver power supply current- At the same time, only one channel is working.- Please allow slightly measuring deviation due to manual measurement.- Due to unavoidable factors such as monitor, shooting angle, light source, etc., the color in the picture may have a very slight color difference with the goods you receive. Everything is subject to the goods you receive.Package include:(optional)1 /4 PCS x RC switch modules, not included light board showing in the pictureWe will be responsible for every buyer, if you find any problem with the product after receiving the package, please feel free to contact us. We will do our best to help you solve all problems.Our products are very rich, including all kinds of drones, four-axis and multi-axis drone accessories, helicopter accessories, model aircraft accessories, etc. If you don't find the accessories you need, you can contact us, we will help you to confirm whether our warehouse is still in stock

• Item name: For CH2-L RC electronic switch / RC switch on off / RC switch modules / led light control board
• RC Electronic Switch With power-on protection, only at the middle position can enter the system
• Max current: 1A/channel, BEC output: no, 5-12V receiver power supply
