LRF600H Long Range LiDAR Sensor, 0.05-600m Range, UART/IIC Interface Laser Rangefinder Module

Introducing the LRF600H LiDAR sensor module, a high-precision laser ranging device that delivers exceptional performance in a compact form factor. With an impressive range of up to 1,968 feet at 90% reflectivity and 656 feet at 10% reflectivity, this sensor provides reliable distance measurements across diverse conditions. The module features automatic frequency switching between 1kHz and 50Hz to optimize signal reception, while maintaining high accuracy of ±3.9 inches for distances under 32.8 feet and 1% for greater distances. Operating at a central wavelength of 905nm with Class 1 photobiological safety rating, it's suitable for various applications. The sensor supports both UART and IIC communication interfaces and operates on 9-36VDC power supply with minimal power consumption of 1.2W. Its compact dimensions of 1.3 x 1.34 x 0.71 inches and lightweight design of 0.7 ounces make it ideal for integration into various systems. The module functions reliably in temperatures from -4°F to +140°F and includes a 19.7-inch 5P stranded wire connection. Customization options are available for appearance, structure, and output protocol to meet specific application requirements.

• MEASUREMENT RANGE: Impressive range of 0.05m to 600m with 90% reflectivity, and up to 200m with 10% reflectivity for versatile distance measurement needs
• HIGH PRECISION: Achieves ±10cm accuracy for distances under 10m and 1% accuracy for distances over 10m, with excellent repeatability
• COMPACT DESIGN: Ultra-compact size of 33 x 34 x 18mm and lightweight construction at just 20g makes it ideal for integration into various systems
• PERFORMANCE SPECS: Features 1kHz/50Hz auto-switching frequency, 905nm wavelength, and 4mrad field of view for reliable measurements
• POWER EFFICIENT: Operates on 9-36VDC with low power consumption of 1.2W average, peak current of 100mA, and supports UART/IIC communication interface
